| TECHNICAL SPECIFICATIONS OF VIRAAT SUPER HEAVY DUTY SPLIT INVERTER AIR CONDITIONERS | ||
| Model Name | AMSi2731260ASHD | |
| Type of AC | Inverter | |
| Cooling Only | ||
| Capacity | Ton | 2.25T |
| Power Supply Source | V | 230V/1Phase/50Hz |
| Cooling Capacity (100%/50%) | W | 8000 / 4000 |
| Max Cooling Capacity | W | 8750 |
| Input Power (100%/50%) | W | 2550 / 805 |
| Annual Power Consumption | Kw/h | 1437.51 |
| ISEER (Cooling) | W/W | 4.31 |
| Star Rating | 3 | |
| Voltage Range | V | 150 ~290 |
| Rated Current | A | 11.6A |
| INDOOR UNIT | ||
| Net Dimensions (LxWxH) | mm | 1260 x 362 x 280 |
| Packing Dimensions (LxWxH) | mm | 1335 x 445 x 366 |
| Weight (Net)/(Gross) | kg | 19.5 / 24.7 |
| Air Flow Volume | m3/h | 1550 |
| Air Throw | ft/mtr | 18.5* |
| Operating Noise Level | dB(A) | 52 |
| OUTDOOR UNIT | ||
| Size | In | 20″ Wide |
| Refrigerant | Type | R32 |
| Net Dimensions (LxWxH) | mm | 780 x 310 x 540 |
| Packing Dimensions (LxWxH) | mm | 918 x 405 x 593 |
| Weight (Net)/(Gross) | kg | 25.8 / 29.8 |
| Operating Noise Level | dB(A) | 62 |
| Liquid Tube Diameter | mm | 1/4″ (6.00mm) |
| Gas Tube Diameter | mm | 1/2″ (12.00mm) |
| *Under Standard Installation and Lab Test Condition | ||
NOTE:
- The images shown are for graphical representation only.
- Amstrad Air Conditioners are designed to work in ambient temperature upto 52 degree centigrade
- There is a continual improvement process for the better performance, changes in design and specifications can be made without prior notice.
- Noise level to be experienced from the distance of one meter from air conditioner.
- All tests are carried at standard conditions.
